Dowel Pin with Internal Thread (DIN7979D)

Harden Steel

Read More:
Catalog Dowel Pin With Internal Thread (DIN7979D)


Size d1 M4 M5 M6 M8 M10 M12 M16 M20
d2 M3 M3 M4 M5 M6 M6 M8 M10
a 0.5MM 0.6MM 0.8MM 1.0MM 1.2MM 1.6MM 2.0MM 2.5MM
c 1.3MM 1.7MM 2.1MM 2.6MM 3.0MM 3.8MM 4.7MM 6.0MM
t1 6MM 6MM 6MM 8MM 10MM 10MM 12MM 16MM
t2 (min) 7MM 7MM 10MM 12MM 16MM 16MM 20MM 25MM
