Hexagon Nut (UNC)
Material:
Steel , Stainless Steel 304 (A2) , Stainless Steel 316 (A4)
Finishing:
Steel comes in Black Oxide and Zinc Plated finishing
Note:
Drop us an email if you have other size or coating requirement
Read More:
Catalog Hexagon Nut (UNC)
| Size | 1/4 | 5/16 | 3/8 | 7/16 | 1/2 | 1/2 BSW | 9/16 | 5/8 | 3/4 |
| T.P.I | 20G | 18G | 16G | 14G | 13G | 12G | 12G | 11G | 10G |
| A/F | 7/16 | 1/2 | 9/16 | 5/8 | 3/4 | 13/16 | 13/16 | 15/16 | 1-1/8 |
| Height | 5.8MM | 7.0MM | 8.6MM | 9.8MM | 11.4MM | 11.4MM | 12.6MM | 14.2MM | 16.9MM |
| Size | 7/8 | 1" | 1-1/8 | 1-1/4 | 1-3/8 | 1-1/2 | 1-3/4 | 2" | |
| T.P.I | 9G | 8G | 7G | 7G | 6G | 6G | 5G | 4.5G | |
| A/F | 1-5/16 | 1-1/2 | 1-11/16 | 1-7/8 | 2-1/16 | 2-1/4 | 2-5/8 | 3" | |
| Height | 19.7MM | 22.5MM | 25.4MM | 27.8MM | 30.7MM | 33.5MM | 38.1MM |
