Lifting Eye Nut (DIN582)
Material :
Steel , Stainless Steel 304 (A2)
Finishing :
Steel comes in Plain finishing
Note:
Drop us an email if you have other coating or size requirement
Read More:
Catalog Lifting Eye Nut (DIN582)
Catalog Lifting Eye Nut (INCHES)
| Size (D1) | M6 | M8 | M10 | M12 | M14 | M16 | M18 | M20 | M22 | M24 | M27 | M30 | M33 | M36 | M39 | M42 | M45 | M48 |
| Pitch | 1.0 | 1.25 | 1.5 | 1.75 | 2.0 | 2.0 | 2.5 | 2.5 | 2.5 | 3.0 | 3.0 | 3.5 | 3.5 | 4.0 | 4.0 | 4.5 | 4.5 | 5.0 |
| D2 | 20MM | 20MM | 25MM | 30MM | 30MM | 35MM | 40MM | 40MM | 40MM | 50MM | 50MM | 65MM | 65MM | 75MM | 75MM | 85MM | 85MM | 100MM |
| D3 | 36MM | 36MM | 45MM | 54MM | 54MM | 63MM | 72MM | 72MM | 72MM | 90MM | 90MM | 108MM | 108MM | 126MM | 126MM | 144MM | 144MM | 166MM |
| D4 | 20MM | 20MM | 25MM | 30MM | 30MM | 35MM | 40MM | 40MM | 40MM | 50MM | 50MM | 60MM | 60MM | 70MM | 70MM | 80MM | 80MM | 90MM |
| H | 36MM | 36MM | 45MM | 53MM | 53MM | 62MM | 71MM | 71MM | 71MM | 90MM | 90MM | 109MM | 109MM | 128MM | 128MM | 147MM | 147MM | 168MM |
| Size (D1) | 1/4 | 5/16 | 3/8 | 1/2 | 5/8 | 3/4 | 7/8 | 1" | 1-1/8 | 1-1/4 | 1-1/2 | 1-3/4 | 2" |
| T.P.I | 20 G | 18 G | 16 G | 13 G | 11 G | 10 G | 9 G | 8 G | 7 G | 7 G | 6 G | 5 G | 4.5 G |
| D2 | 20MM | 20MM | 25MM | 30MM | 35MM | 40MM | 40MM | 50MM | 65MM | 75MM | 85MM | 100MM | 100MM |
| D3 | 36MM | 36MM | 45MM | 54MM | 63MM | 72MM | 72MM | 90MM | 108MM | 126MM | 144MM | 166MM | 166MM |
| D4 | 20MM | 20MM | 25MM | 30MM | 35MM | 40MM | 40MM | 50MM | 60MM | 70MM | 80MM | 90MM | 90MM |
| H | 36MM | 36MM | 45MM | 53MM | 62MM | 71MM | 71MM | 90MM | 109MM | 128MM | 147MM | 168MM | 168MM |
