Socket Set Screw With Cone Point (DIN914)

Material :
Steel , Stainless Steel 304 (A2)

Finishing :
Steel comes in Black Oxide Finishing

Note:
Drop us an email if you have other coating requirement

Diameter (d) M3 M4 M5 M6 M8 M10 M12
Pitch 0.5 0.7 0.8 1.0 1.25 1.5 1.75
kmax 2MM 2.5MM 3MM 3.5MM 5MM 6MM 8MM
s 1.5MM 2MM 2.5MM 3MM 4MM 5MM 6MM
dtmax - - - 1.5MM 2MM 2.5MM 3MM
Length (L)
  • 3MM
  • 4MM
  • 5MM
  • 6MM
  • 8MM
  • 10MM
  • 12MM
  • 3MM
  • 4MM
  • 5MM
  • 6MM
  • 8MM
  • 10MM
  • 12MM
  • 16MM
  • 5MM
  • 6MM
  • 8MM
  • 10MM
  • 12MM
  • 16MM
  • 20MM
  • 6MM
  • 8MM
  • 10MM
  • 12MM
  • 16MM
  • 20MM
  • 25MM
  • 8MM
  • 10MM
  • 12MM
  • 16MM
  • 20MM
  • 25MM
  • 10MM
  • 12MM
  • 16MM
  • 20MM
  • 25MM
  • 12MM
  • 16MM
  • 20MM
  • 25MM
